ADX (Average Directional Index)

Wilder's ADX measures how much direction the move has, on an unsigned 0–100 scale: above 25 the trend dominates the noise, below 20 there is no trend to follow. Direction comes from +DI and −DI.

Cite this entry

This reference cites the Cyclepedia entry. The documents it draws on are listed in the entry’s sources.

On this page

The ADX, published by J. Welles Wilder in New Concepts in Technical Trading Systems (1978), answers the question that comes before all others: is there a trend, or not? Almost every tool in the catalogue works well in one regime and badly in the other — averages and their crossovers live off trends, oscillators do their best work in ranges. The ADX is the instrument that decides which family makes sense to use.

In plain terms — The ADX does not tell you whether the river flows north or south: it tells you how strong the current is. With a strong current you row with it; without one, river techniques are useless.

How it is built

Wilder splits each bar into two pushes: positive directional movement (+DM, how far today's high exceeds yesterday's) and negative (−DM, how far today's low undercuts yesterday's). Normalised by the ATR, they become +DI and −DI: buyers' pressure and sellers' pressure. The ADX is the (14-period) average of the imbalance between the two — when one dominates, the ADX rises; when they balance out, it falls. The sign is lost by construction: the ADX also rises in a downtrend, because it measures dominance, not direction.

ADX Common reading
< 20 No dominant trend — range regime
20–25 Transition: a trend may be forming
> 25 Defined trend — trend-following tools work
> 40 Very strong (and often mature) trend

How to read the chart — Top: a market going from range to trend and back to range. Bottom: ADX (blue), +DI (green), −DI (red), dashed gold 25 threshold. Interactive — the highlighted points show the ADX crossing 25 as the trend starts, the peak flagging strength exhaustion, and the sub-20 zone.

INDICATOR · TREND ADX — how much direction the move has ADX = strength (unsigned) · +DI/−DI = the two directional pushes CYCLEPEDIA DIAGRAM — EMICICLO PRICE: RANGE → TREND → RANGE Price 103 108 113 ADX (14) · +DI · −DI 25 40 ADX +DI −DI > 25 ADX PEAK IN THE PERIOD 72 BARS WITH ADX > 25 39 of 39 The question before all others: is there a trend? ADX answers that one only
The ADX rises while the trend develops and rolls over when directional strength stops growing — even though price has not fallen yet.
Select the highlighted points to explore the detail

Reading it in practice

  1. Regime filter — the main use: ADX below 20 → shelve moving-average crossovers, directional MACD and aggressive breakouts, and work with range tools (Stochastic, bands). Above 25 → the opposite.
  2. Rising vs falling ADX — the slope matters more than the level: an ADX at 22 rising steeply describes a trend being born; an ADX at 35 rolling over describes a trend growing old. The ADX peak is not the price peak: it marks the peak of the move's quality.
  3. +DI/−DI crossovers — they show which push dominates; taken alone they produce many false signals, filtered with ADX > 25 they become readable.

Limits and traps

Warning — The ADX is doubly slow: it is built from Wilder averages applied to averages. It confirms trends late and declares them dead late. Use it as a context filter, never as entry timing.

  • A high ADX does not mean "buy": it only means the move in progress, in whatever direction, is orderly.
  • On very short timeframes the measurement gets dirty: a few minutes of directional imbalance is often just noise.
